RT2-L
Main Features:
  • UL and CUR safety approval.
  • PCB mounting and quick connect terminals be used for various application.
  • Up to 30amps switching in SPNO and 20amps switching in SPDT arrangement.
  • Suitable for various industrial.
  • RoHS 2011/65/EU compliant.
LxWxH(mm) 32.3x26.9x28.1
Arrangement 1a, 1c
Contact Current 20A, 30A
Contact Rating
1a:
250VAC 30A
30VDC 30A
250VAC 2HP
125VAC 1HP
1c:
NO:250VAC/30VDC 30A
NC:250VAC/30VDC 20A
250VAC 2HP
125VAC 1HP
Coil VoLtage DC 5-48VDC
AC
Coil Power DC 0.93W
AC
Insulation Resistance DC500V 100MΩ
Dielectric Strength 1500VAC
between coil & contact
Life Mechanically 1x107
Electriaclly 1x105
